Features
Frequency response: 20Hz to 20kHz flat within +/-0.1dB (HF filter off)
Tap length filter: 164,000 THD + N: 127.5dB (AWT)
Channel separation: >125dB @ 1KHz
Dynamic range: 127.5dB (AWT)
Sample frequencies: 44.1Khz – 768Khz (16 – 32bit) and DSD64 to DSD512 native DSD + DoP (input dependant)
Digital inputs:
4x 75Ω S/PDIF BNC Coax – 44.1kHz to 384kHz
1x AES XLR – 44.1kHz to 96kHz
2x Fibre Optic TOSLINK – 44.1kHz to 96kHz
1x USB Type B – 44.1kHz to 768kHz (16 – 32bit) – PCM and DSD
Analogue outputs:
1x Stereo Pair of Unbalanced RCA
1x Stereo Pair of Balanced XLR
1x ¼” TRS Jack Headphone Output
Specifications
Frequency Response:
20Hz to 20kHz +/- 0.1dB
THD +N:
-127.5dB (AWT)
Channel Separation:
>125dB @ 1kHz
Dynamic Range:
127.5dB (AWT)
Headphone Output:
1% THD 6.8v RMS with 300Ω (154mW)
1% THD 6.8v RMS with 33Ω (1.4w)
Output Impedance:
0.055Ω (short circuit protected)
Operating voltage:
90v AC – 250v AV auto switching 50Hz – 60Hz
Power consumption:
Full power – 40 W
Standby – 10 W
Dimensions (including connectors):
7.8cm (H) 33.5cm (W) 15.2cm (D)
Weight:
5kg
