Features
Psycho-acoustically optimized digital and analogue filters
24-bit resolution, up to 192 kHz sample rates, DSD64
3 stages of jitter reduction
3 user-selectable digital filter settings
Group delay-optimized analogue output filter
Fully balanced signal path from the DA converter to output stage
True Peak Technology creates headroom for Intersample Overloads
Roon module (optional) rendering DAC as streaming endpoint
Backlit remote control with rotary volume dial
MBL Smartlink capable
5” TFT Color Display for track information, text recognition, album artwork
1 VA “green” standby
Specifications
Digital Inputs
1 x Toslink (Snap-In-type)
1 x S/P-DIF (RCA)
1 x AES/EBU (XLR)
1 x USB1: USB Audio Class 1 (Typ B)
1 x USB2: USB Audio Class 2 (Typ B)
Digital Outputs
1 x Toslink (Snap-In-type)
1 x S/P-DIF (RCA) 1 x AES/EBU (XLR)
Analogue Outputs
1 x RCA 1 x XLR
Other Inputs/Outputs
MBL SmartLink SD slot for updating
Resolution / Sample Rates
16 / 24 bit 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz DSD
Weight
18 kg / 39.7 Ibs
